SONEX One Noise Reduction Panels

$335.00$718.00

NRC Range: 0.85 – 1
Tile size: 24″ x 48″

SONEX One noise reduction panels are versatile and provide effective acoustic control in a variety of applications and environments including industrial facilities, multipurpose rooms and architectural projects.

acouSTIC Adhesive sold separately.

  • NRC Range: 0.85 - 1.0
Limit of 10 boxes per order. Please call 800-662-0032 for purchases over 10 boxes.
COLORS: Colors do not necessarily reflect the actual color of the product.
SHIPPING TIME: Natural Finishes typically ship same day to 10 days, Standard Painted finishes typically 10 to 15 days and Premium Colors 15+ days.
SHIPPING RESTRICTION: Due to Proposition 65 and local building codes and regulations, polyurethane foam cannot ship into the state of California.

SONEX One noise reduction panels are attractive and reliable, featuring Noise Reduction Coefficient (NRC) ranging from 0.85 to 1.10. The sculpted surface of each panel deflects and disperses sound waves, allowing the open-cell willtec® foam to convert sound energy into quiet, kinetic energy.

SONEX One panels are available in natural, colortec™ and water-based HPCcoated finishes. Our exclusive HPC formulation protects the foam from dust and dirt and makes it possible to wipe panels clean using only a damp cloth. Panels are also available in colortec (the entire thickness of the foam is dyed a deep charcoal).

These panels are especially appropriate for high-traffic areas. SONEX One panels are easy to install on any wall and/or ceiling surface with SONEX’s acouSTIC water-based adhesive. The panels can also be used in conjunction with SONEX One baffles, which have the same pattern but are designed to hang from ceilings in large rooms or open interior spaces.

Additional Information

Product Information

Physical Data
Sound Absorption Data

Size

  • Typical panel size: 24″x 48″ (610 x 1219 mm)
  • Typical thickness options: 2″ and 3″

Applications

  • Retail stores
  • Printing rooms
  • Production facilities
  • Aquatic and recreation centers
  • Education facilities and daycare centers

Material

  • Made from open-cell, natural light grey or white WILLTEC® expanded melamine foam
  • Standard water-based acoustic coating color options in arctic white, ivory, beige, light blue, light, medium or dark grey, black and other premium or custom options are available; panels coated on one side and all edges standard
  • Non-repeating, omni-directional pattern, square-edge panels standard; optional 15, 22.5, 30 and 45-degree bevel edges also available
Direct-Apply, Glue-up Installation

  • Use clean, thin, white cotton gloves to handle panels
  • Cut acouSTIC™ adhesive cartridge tip to produce ¼ inch (6.4 mm)-diameter bead
  • Run a continuous bead of adhesive around the panel’s perimeter, approximately 1.5 inch (38 mm) from edges, then apply intermittent beads from opposite corners through the center of the panel creating an X
  • Press panel firmly into place and smooth evenly across it to ensure a strong, lasting bond; adhesive tack should be immediate

Installation

acouSTIC adhesive (part number PA-02) has been specially formulated to use with all SONEX®, WILLTEC®, CONTOUR®, WHISPERWAVE panel products, PROSPEC® Foams and Composites. This nontoxic, practically odorless, water-based adhesive makes direct-apply, glue-up installation work quick and easy. acouSTIC adhesive provides an immediate tack between panels and most substrates making for strong, permanent bonds. Other adhesives may not be compatible and may emit an odor.

acouSTIC Foam Adhesive

Features

Nontoxic, water-based adhesive.
Easy cleanup with soap and water.
Compatible with both polyurethane and WILLTEC foams.
Each 10.3-ounce (304.61 ml) tube installs between 16 and 24 square feet (1.49 and 2.23 square meters) panel coverage.
Tube fits standard caulking guns.

General Installation Notes

Handle with care. Do not pick up or handle panels by the corners.
Store panel boxes flat in clean, dry areas protected from the elements; excessive heat, cold and humidity.
Do not set or stack anything on top of cartons.
Work panels with clean hands, tools, ladders, etc. on clean work surfaces. Wear clean, soft white cotton gloves to handle panel installation, recommended.
Super sharp, stainless steel smooth long-blade insulation knives are ideal for making straight cuts, slicing through thick WILLTEC and SONEX panels. Shorter-length utility and extendable snap-off blade knives are best suited for making smaller detail cuts.
For best results, cut panels through ‘exposed-to-view’ panel faces.

Installation with acouSTIC

Make certain that substrate surfaces to which panels will be applied are smooth, clean and level; free of dust, dirt and other residues or contaminants which could inhibit a strong bond to develop.
Cut adhesive tube tips back to produce a bead flow of 1/4 inch (6.4 mm) diameter.
Run a continuous bead of adhesive around the panel’s perimeter, approximately 1.5 inch (38 mm) from edges, then apply intermittent beads from opposite corners through the center of the panel creating an X.
Press panels firmly into place and smooth evenly across them to ensure a strong, lasting bond; adhesive tack should be immediate.

General Characteristics

General tolerances & dimensions stability

Thickness:
– Up to 2” – tolerances of +/- 2 MM = +/- 0.08”
– Above 2” – tolerances of +/- 3 MM = +/-1/8”

Length & width:
– Up to 24” tolerance of +/- 3 MM = 1/8”
– Up to 96” tolerance of +/- 6 MM = 1/4”

Sonex convolution (sonex one / valueline / classic / mini / junior):
– Pattern alignment to edge: +/-1”

Due to the nature of willtec material, temperature and humidity may cause dimensional changes of up to 4% by volume.

Color Chart

Natural WILLTEC®

white

grey

Coated WILLTEC®

arctic white

medium grey

light grey

black

COLORTEC®

black*

*Color is impregnated in the foam and has a water-based acoustic coating on top.

Premium HPC Paint Colors

Vermillion

Vermillion

Orange Red

Orange Red

Frost

Frost

Superior

Superior

Olive

Olive

Yellow

Sweet Corn

Black

Brown Black

Dark Grey

A minimum order of five boxes is required for premium colors.

Polyurethane

Polyurethane brown

brown

Polyurethane charcoal

charcoal
