SONEX Clean Washable Ceiling Tiles

$549.00$675.00

NRC Range: 0.80
Sheet size: 24″ x 24″ and 24″ x 48″
SONEX Clean washable ceiling tiles are designed for environments that require excellent noise control across all sound frequencies using easy to clean acoustic materials. These cleanable vinyl wrapped ceiling tiles are ideal for commercial kitchens in restaurants, food or beverage processing facilities, clean rooms, indoor pools and more.

  • NRC Range: 0.8
COLORS: Colors do not necessarily reflect the actual color of the product.
SHIPPING TIME: Natural Finishes typically ship same day to 10 days, Standard Painted finishes typically 10 to 15 days and Premium Colors 15+ days.
SHIPPING RESTRICTION: Due to Proposition 65 and local building codes and regulations, polyurethane foam cannot ship into the state of California.

SONEX Clean washable ceiling tiles have excellent noise control across all sound frequencies. Easy to clean, SONEX Clean vinyl wrapped ceiling tiles are ideal for restaurant and commercial kitchens, food processing plants, clean rooms and more. Suitable for suspended ceiling grid panel applications, the product is fully encapsulated in FR taffeta vinyl for efficient cleaning and long-lasting durability. SONEX Clean products meet USDA/FDA requirements.

Additional Information

Product Information

Sound Absorption Dat
Sound Absorption

Size

  • Direct-apply, glue-up panels: 24” x 48” x 2” (610 x 1219 x 51 mm)
  • Suspended ceiling panels: 23-¾” x 23-¾” x 2” or 23-¾” x 47-¾” x 2” (603 x 603 x 51 or 603 x 1213 x 51 mm)
  • Suspended baffles: 26” x 48” x 2” (660 x 1219 x 51 mm) includes 2” (51 mm) top tab height

Applications

  • Clean rooms, scientific and medical research labs
  • Aerospace and optics manufacturing facilities
  • Bottling and food processing plants
  • Commercial kitchens
  • Indoor swimming pools

Material

  • Made from ASTM E 84 Class A, CAN ULCS-102 fire rated, lightweight, non-fibrous WILLTEC® expanded melamine foam core
  • Fully encapsulated in FR taffeta vinyl
  • Reseal tape is included

Installation

Direct-Apply, Glue-Up Panels

  • Use PA-02 or PA-03 acouSTIC adhesive, mock-up to test for best adhesion recommended
  • SONEX Clean resealing tape available for cut-to-fit panel conditions onsite

Suspended Ceiling Panels

  • Fits within most standard 15/16” (24 mm) ceiling grid system

Suspended Baffles

  • Produced with integral grommets along top tabs to easily loop suspension wire through

Installation

Direct-Apply, Glue-Up Panels
– Use PA-02 or PA-03 acouSTIC adhesive, mock-up to test for best adhesion recommended
– SONEX Clean resealing tape available for cut-to-fit panel conditions onsite

Suspended Ceiling Panels
– Fits within most standard 15/16” (24 mm) ceiling grid system (not provided)

Suspended Baffles
– Produced with integral grommets along top tabs to easily loop suspension wire through

General Characteristics

General tolerances & dimensions stability

Thickness:
– Up to 2” – tolerances of +/- 2 MM = +/- 0.08”
– Above 2” – tolerances of +/- 3 MM = +/-1/8”

Length & width:
– Up to 24” tolerance of +/- 3 MM = 1/8”
– Up to 96” tolerance of +/- 6 MM = 1/4”

Sonex convolution (sonex one / valueline / classic / mini / junior):
– Pattern alignment to edge: +/-1”

Due to the nature of willtec material, temperature and humidity may cause dimensional changes of up to 4% by volume.

Color Chart

Sonex Clean colors
