Home Theater Sound Absorbing Panels
Noise Control in Bar

WHISPERWAVE Acoustic Clouds

$332.00 – $548.00

NRC Range: 0.95 (11.50 Sabins)
Sheet size: 24″ x 48″
WHISPERWAVE Clouds provide exceptional acoustical control and design flexibility.

Baffle corkscrews and cables sold separately.

  • NRC Range: 0.95 (11.50 Sabins)
Quantity Discount (%) Price
1 - 9 — $418.00
10+ 8.85 % $381.00
Limit of 10 boxes per order. Please call 800-662-0032 for purchases over 10 boxes.
COLORS: Colors do not necessarily reflect the actual color of the product.
SHIPPING TIME: Natural Finishes typically ship same day to 10 days, Standard Painted finishes typically 10 to 15 days and Premium Colors 15+ days.
SHIPPING RESTRICTION: Due to Proposition 65 and local building codes and regulations, polyurethane foam cannot ship into the state of California.

Lightweight and easy to install, WHISPERWAVE Acoustic Clouds reduce sound reverberation and eco in classrooms, cafeterias, multipurpose rooms, indoor swimming pools, offices, libraries, religious facilities and other large open areas.

Additional Information

Weight 5.45 kg
Dimensions 49 × 25 × 13 in

Product Information

Physical Data
Sound Absorption Data

Size

  • Any dimension up to 48″ x 96″
  • 2″ and 3″ thicknesses
  • Custom baffle sizes available

Applications

  • Multipurpose rooms and gymnasiums
  • Large classrooms or music rooms
  • Manufacturing facilities
  • Aquatic centers and indoor pools
  • Any large, open room with reverberation problems

Material

  • Made from willtec® foam, which is Class 1 fire-rated according to ASTM E 84 for flame spread and smoke density.
  • Standard water-based acoustic coating color options in arctic white, ivory, beige, light blue, light, medium or dark grey, black and other premium or custom options are available

Installation

  • Corkscrew hangers are installed in the field for ceilingmounted cable installation

General Characteristics

General tolerances & dimensions stability

Thickness:
– Up to 2” – tolerances of +/- 2 MM = +/- 0.08”
– Above 2” – tolerances of +/- 3 MM = +/-1/8”

Length & width:
– Up to 24” tolerance of +/- 3 MM = 1/8”
– Up to 96” tolerance of +/- 6 MM = 1/4”

Due to the nature of willtec material, temperature and humidity may cause dimensional changes of up to 4% by volume.

Color Chart

Natural WILLTEC®

white

grey

Coated WILLTEC®

arctic white

medium grey

light grey

black

COLORTEC®

black*

*Color is impregnated in the foam and has a water-based acoustic coating on top.

Premium HPC Paint Colors

Vermillion

Vermillion

Orange Red

Orange Red

Frost

Frost

Superior

Superior

Olive

Olive

Yellow

Sweet Corn

Black

Brown Black

Dark Grey

A minimum order of five boxes is required for premium colors.

Polyurethane

Polyurethane brown

brown

Polyurethane charcoal

charcoal
